| TIPE SHAFT |
Flexible Shaft |
| CUTTER |
Tipe |
2- Blade Cutter |
| Diameter X Langkah |
300 mm |
| RPM |
5250 rpm (7,000 rpm) |
| PANJANG x LEBAR x
TINGGI |
2625 x 345 x 460 |
| THROTTLE TYPE |
2- Lever Throttle
system |
| BERAT BERSIH |
10,1 Kg |
| BERAT OPERASIONAL |
10.6 Kg |
| MESIN |
Model |
GX35T |
| Tipe |
Silinder Tunggal OHC,
4- Tak |
| Isi Silinder |
35.8 cm³ |
| Diameter X Langkah |
39 x 30 mm |
| Tenaga Maksimum |
1.0 kw (1.2 PS) @7000
rpm |
| Torsi Maksimum |
1.6 N-m / 5500 rpm |
| Perbandingan Kompresi |
8:01 |
| Konsumsi Bahan Bakar |
360 g/kW-h (265
g/PS-h) |
| Sistem Pengapian |
Transistorized
Magneto Ignition |
| Pembersih Udara |
Semi-dry |
| Kapasitas Oli |
0.10 Liter |
| Sistem Penyalaan |
Recoil Starter |
| Kapasitas Bahan Bakar |
0.65 Liter |
