| Model |
SHW190 |
| Type |
R |
| Generator |
Frekuensi (Hz) |
50 |
| Tipe |
2-Pole,Field Rotating Type |
| Fase |
Single |
| AC Output |
Hasil Rata-rata (KVA) |
50Hz |
2,0 |
| 60Hz |
- |
| Voltase rata-rata (V) |
220 |
| Faktor Daya Rata-rata (cosc) |
1,0 |
| Welder (DC) |
Tipe |
2-Pole,Field Rotating Type |
| Rectifilter Type |
Six Phase Hlf Wave Rectifier |
| Hasil Rata-rata |
3600rpm |
140A 26A |
| Current Contrpl Range (A) |
50-190 |
| Rated Duty Cycle (%) |
50-190 |
| Welding |
2,6 to 5,0 mm dia |
| Mesin |
Pembuat |
HONDA |
| Model |
GX390 |
| Kapasitas cilinder (cc) |
389 |
| Hasil Maksimum (PS) |
3600rpm |
13 |
| Sistem Pengapian |
Transistor |
| Sistem Peringatan Oli |
YES |
| Sistem Starter |
.Recoil (OP;Electric) |
| Lainnya |
L X W X H (mm) |
679x511x490 |
| Berat Kering (kg) |
88 |
| Kapasitas Tangki (liter) |
17 |
| Ukuran Suara [dB(A)/7m] |
50Hz |
73 |
| 60Hz |
75 |
| Jma Operasi berkelanjutan (Jam) |
50Hz |
6,2 |
| 60Hz |
5,2 |
