| MAIN UNIT |
Power
transmission |
Automatic
centrifugal clutch,Spiral |
| Maximum speed of gearshaft |
7000 |
| Engine speed (r/min) |
9000 |
| Idle speed (r/min) |
2500/150 |
| Vibration values at each handle |
15 (m/s) |
| Soun pressure values (in accordance with EN ISO
11806:1997,EN 27917:1987) |
102 (dB(A)) |
| Sound power values ( in accordance with ISO 10884 ) |
120 (dB(A)) |
| Reduction ratio |
17;22 |
| Blade rotation direction |
Counter-Clockwise(seen
from the top) |
| Handle type |
Loop Handle |
| Weight when dry (kg) |
10 |
| Engine |
Name of engine |
1E36F.0 |
| Type |
Air-cooled;2
cycle vertical;piston valve;gasoline engine |
| Displacement (ml) |
32.8 |
| Maximum output (kW/r/min) |
0.85/6500 |
| Carburetor |
Huayi,Float-type |
| Ignition |
Non-contac electronic
ignition |
| Starting method |
Recoil type |
| Fuel used |
Gasoline mixed with
2-T oil (ratio of 30;1) |
| Fuel tank capacity |
1,4 |
| Dry weight (kg) |
3,85 |
| Spark plug |
Torch AT 4117 |
| Flywheel |
Ikeda |
| Shaft & Blade |
Length of main pipe
section (mm) |
1360 |
| Length of drive shaft section (mm) |
1255 |
| Length of inner flexible shaft (mm) |
840 |
| Standard blades (mm) |
1-blade(305x90x1,6) |
