| TIPE
MESIN |
Silinder
tunggal OHV 25°, 4-Tak berpendingin udara |
| DIAMETER x
LANGKAH (mm) |
68.0 x 45.0 |
| ISI SILINDER
(cm³) |
196 |
| PERBANDINGAN
KOMPRESI |
8.5 |
| TORSI
MAKSIMUM (N.m)@2500rpm |
12.4* |
| TENAGA
BERSIH (Kw)@3600rpm |
4.1* |
| PENGGUNA
BAHAN BAKAR (L/H)@continuous rate Power |
1.7* |
| SISTEM
PENGAPAIAN |
Transistorized Type
Magneto Ignition |
| KAPASITAS
TANGKI BAHAN BAKAR (L) |
3.1 |
| SISTEM
PELUMASAN |
Forced Spray System |
| KAPASITAS OLI
(10W-30SJ)** (L) |
0.6 |
| SISTEM
PENYALAAN |
Recoil Stater |
| BERAT KERING
(KG) |
16 |
| DIMENSI : P x
L x T (mm) |
315 X 378 X 335 |
| TINGKAT
KEBISINGAN [db(A)]@continuous rate Power |
91 (1m) |
