| GENERATOR |
AC FRECUENCY |
50 Hz |
| AC OUTBUT VOLTAGE |
220 V |
| RATE AC OUTPUT |
1.8 Kva |
| MAXIMUM AC OUTPUT |
2.2 Kva |
| DC OUTPUT |
12V- 8.3A |
| ENGINE |
MODEL |
GXR120T |
| TYPE |
Air-cooled
4-stroke OHV single-cylinder |
| DISPLACEMENT |
121 cm3 |
| IGNITION SYSTEM |
Fully transistorized |
| STARTING SYSTEM |
Recoil |
| MAXIMUM POWER OUTPUT |
2.2 kw/4500 rpm |
| FUEL TANK CAPACITY |
3.6 lit |
| CONTINUOUS OPERATION HOUR ( 1/4 Load ) |
8.1
hrs* |
| (*tested with US type) |
| (rated load) |
3.2 hrs |
| OPERATING NOIS LEVEL (at 7m) (1/4 load) |
53 db(A)* |
| (rated load) |
65 db(A) |
| NOISE LEVEL Lwa |
90 |
| DIMENSION |
DIMENSION LxWxH (mm) |
509x290x425 |
| DRY WEIGHT (Kg) |
21.1 |
| STANDARD FEATURES |
FUEL INJECTION SYSTEM |
Not Available |
| ECO- THROTTLE |
? |
| AC CIRCUIT PROTECTOR |
? |
| DC CIRCUIT PROTECTOR |
? |
| OLI ALERT |
? |
| LARGE- CAPACITY AIR CLEANER |
? |
| LARGE- CAPACITY FUEL TANK |
? |
| LARGE- CAPACITY MUFFLER |
? |
| PARALLEL OPERATION CONNECTION PORTS |
? |
| PARALLEL OPERATION CONNECTION CABLE |
Option |
| Imonitor |
- |
| REMOTE CONTROL BOX |
- |
| WHEEL DOLLY KIT |
- |
