| TYPE |
RRH |
| GENERATOR |
FREQUENCY (Hz) |
50 |
| PHASE |
Single Phase |
Three Phase |
| RATED
AC VOLTAGE (V) |
220 |
380 |
| RATED
AC CURRENT (A) |
12.1x3 |
15.2 |
| RATED
AC OUTPUT (KVA) |
2.7x3 |
10 |
| MAXIMUM
OUTPUT (AC)(KVA) |
3.0x3 |
11 |
| VOLTAGE
REGULATION SYSTEM |
digital A.V.R |
| ENGINE |
MODEL |
GX630H |
| TYPE |
GCAJH |
| DISPLACEMENT
(Cm³) |
688 |
| INGITION
SYSTEM |
CDI Magnet Ignition |
| STARTING
SYSTEM |
Starter Motor |
| FUEL
TANK CAPACITY (L) |
31 |
| RATED
CONTINUOUS OPERATIONAL TIME (h) |
6.5 |
| NOISE
LEVEL (Lwa) |
SOUND
POWER LEVEL @Rated Output |
99.3 |
| DIMENSIONS |
L x W x H (mm) |
973 X 552 X 695 |
| |
DRY MASS (Kg) |
162.3* (Includes Battery |
| EQUIPMENT SPECIFICATION |
CIRCUIT BREAKER [AC (A)] |
17 (Three Phases) /
17 (Single Phase) |
| OLI
ALERT |
? |
| AIR
CLEANER |
Dual |
| LARGE
CAPACITY FUEL TANK |
? |
| MUFFLER |
Exculusive Large Muffler |
| BATTERY
& WHEEL KIT |
? |
