| Tenaga
maksimum @3600 (hp) |
30 |
| Isi silinder (cc) |
747 |
| Bore (mm) |
83 |
| Stroke (mm) |
69 |
| Cylinder |
V-Twin |
| Torsi puncak bersih @max (Nm) |
61 @2400 rpm |
| Rasio kompresi |
9;4;1 |
| Berat kering (kg) |
47 |
| Tipe shaft |
Horizontal |
| Kapasitas oli (L) |
1,9 |
| Tipe pelumas |
Full-pressure lubrication with full-flow filter |
| Dimensi (PxLxT) (mm) |
Flat air cleaner;356x450x483 /
Heavy duty air cleaner;356x450x673 CH750 356x450x706 |
| Tipe mesin |
Four cycle,bensin,OHV,cast iron
cylinder liners,blok alumunium |
| Fitur tambahan |
Kapasitas udara yang
besar,penyaring oli dan bahan bakar,busi berkinerja tinggi,pengangkat kutub
hidrolik,karburator 2 laras |
| Diameter sahft |
1,125 inch |
